Electronic Properties:
Circuit rating: 35V（DC），100mA，1W
Contact resistance: 10Ω~500Ω (vary according to length of lead-out wire and material)
Insulation resistance: 100MΩ 100V
Dielectric withstand voltage: 250V Rms (50-60Hz 1min) without breakdown and arcing after test
Contact chatter time: ≤5ms
Service life: Plane type ≥ 5 million times
Touch type: ≥ 1 million times
Mechanical Properties:
Operating pressure: Plane type: 57~284g（2~10oz）
Touch type: 170~397g（6~14oz）
Switch stroke: Plane type: 0.1~0.5mm
Touch type: 0.6~1.5mm
Environmental Parameters:
Operating temperature: Plane type (including elastic sheet): -20℃~+80℃
Tactile: -20℃~+60℃
Storage temperature: Plane type (including elastic sheet): -40℃~+80℃
Tactile: -40℃~+60℃
Humidity: 40℃,90%～95%,240 hours
